MIL-DTL-10035L
TABLE III. End item dimensional defects (cont'd)
Classification
Examine
Defect
Major Minor
A
B
Cover (cont'd)
on drawing, but not smaller than
specified dimensions less twice the
applicable minus tolerance
302
Smaller than specified dimensions less
twice the applicable minus tolerance
indicated on drawing
201
Larger than specified dimensions and
applicable plus tolerance indicated
on drawings
303
Component dimensions
Webbing, tie tapes
Finished length less than specified by
more than 1 inch
304
Reinforcements
Finished dimensions less than specified
by more than ½ inch
305
Any spliced piece less than 2 feet
in length
306
Snow cloths
Less than specified width by more
than 1 inch
307
Toggle loops
Free ends of loop extending less than
¾ inch beyond edge of flap
308
Ventilator duct
Under or over specified dimensions
opening
by more than ½ inch
309
Location dimensions
Not within the specified tolerance
202
(unless otherwise
specified)
Webbing and tie
Out of specified location:
tapes
-by more than ¼ inch but not
more than ½ inch
203
-by more than ½ inch
102
Distance between splices on all
reinforced places on tent and
liner less than 5 feet
310
4.4.5 End item testing. Tent samples shall be tested as specified in 4.5.1 for compliance with 3.3.7.
The lot shall consist of all completely fabricated tents offered for inspection at one time. The sample unit
shall be one completely fabricated tent. The inspection level shall be S-3. Failure in any area shall be
rejection of the lot.
4.4.6 Packaging examination. The fully packaged end items shall be examined for marking, materials,
workmanship and content defects.
21
